Haier whole-house heat pump is a high-efficiency, multi-functional, environmentally friendly home heating system. It uses heat pump technology to convert heat energy from nature into comfortable indoor temperatures, saving energy and reducing carbon emissions.
Model |
HPM |
HPM |
HPM |
HPM |
HPM |
||
08-Nd2 |
10-Nd2 |
12-Nd2 |
14-Nd2 |
16-Nd2 |
|||
Intended use of the units |
Low and medium temperature application |
||||||
Power supply |
V / Ph / Hz |
220-240/1/50 |
|||||
Heating |
Capacity |
kW |
8 |
10 |
12 |
14 |
16 |
Rated power input |
kW |
1.62 |
2.08 |
2.45 |
2.74 |
3.25 |
|
COP |
kW/kW |
4.95 |
4.8 |
4.9 |
5.11 |
4.92 |
|
Heating |
Capacity |
kW |
8 |
10 |
12 |
14 |
16 |
Rated power input |
kW |
2.42 |
3.03 |
3.43 |
4.24 |
5 |
|
COP |
kW/kW |
3.3 |
3.3 |
3.5 |
3.3 |
3.2 |
|
Cooling |
Capacity |
kW |
8 |
10 |
11.4 |
14 |
16 |
Rated power input |
kW |
1.63 |
2.15 |
2.78 |
2.74 |
3.33 |
|
COP |
kW/kW |
4.9 |
4.65 |
4.1 |
5.11 |
4.8 |
|
Cooling |
Capacity |
kW |
8 |
10 |
11.4 |
14 |
16 |
Rated power input |
kW |
2.5 |
3.33 |
4.07 |
4.52 |
5.51 |
|
COP |
kW/kW |
3.2 |
3 |
2.8 |
3.1 |
2.9 |
|
SCOP |
Average climate |
35℃ |
4.9 |
4.9 |
4.9 |
5.2 |
4.9 |
Average climate |
55℃ |
3.85 |
3.85 |
3.85 |
3.9 |
3.9 |
|
Season space heating energy efficiency class |
Average climate |
35℃ |
A+++ |
A+++ |
A+++ |
A+++ |
A+++ |
Average climate |
55℃ |
A+++ |
A+++ |
A+++ |
A+++ |
A+++ |
|
SEER |
Fan coil application |
7℃ |
4.5 |
4.5 |
4.5 |
5.1 |
5.1 |
Cooling floor application |
18℃ |
6.3 |
6.5 |
6.2 |
7.0 |
7.0 |
|
Refrigerant |
Type |
- |
R290 |
||||
Charge |
kg |
1.3 |
1.3 |
1.35 |
1.95 |
1.95 |
|
E-Heater Backup |
kW |
3.0 |
3.0 |
3.0 |
6.0 |
6.0 |
|
Sound Pressure(1m) |
dB |
45 |
49 |
51 |
51 |
51 |
|
Water pump |
Rated water flow |
m3/h |
1.38 |
1.72 |
2.06 |
2.41 |
2.75 |
Total water head |
m |
12.5 |
12.3 |
12 |
11.5 |
11.1 |
|
Available water head |
m |
9 |
8.8 |
8.5 |
8 |
7.6 |
|
Maximum working pressure of refrigerant |
Mpa |
0.85/3.2 |
|||||
Water side safety valve |
Mpa |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
|
Water proof grade |
/ |
IPX4 |
|||||
Water side connection |
in |
1 |
1 |
1 |
1 |
1 |
|
Net dimension |
W*D*H |
mm |
1312x470x990 |
1312x470x1370 |
|||
Package dimension |
W*D*H |
mm |
1362x567x1167 |
1362x567x1560 |
|||
Ambient temperature range |
Cooling |
℃ |
10-48 |
||||
Heating |
℃ |
-30-35 |
|||||
DHW |
℃ |
-30-43 |
|||||
Leaving water temperature range |
Cooling |
℃ |
5-25 |
||||
Heating |
℃ |
24-75 |
|||||
DHW |
℃ |
30-60 |
product advantages:
1.High efficiency: Haier whole-house heat pumps are characterized by high efficiency and can convert low-temperature heat energy in the outdoor environment into high-temperature heat energy, thereby providing comfortable indoor temperatures. Compared with traditional heating methods, it can save energy consumption and effectively control operating costs.
2.Multifunctional: Haier whole-house heat pumps can not only provide heating services, but also provide cooling services to users in summer, making the living environment more comfortable. In addition, it also has multiple functions such as dehumidification and air purification.
3.Environmental protection: Haier whole-house heat pump uses green energy, does not produce pollution and greenhouse gases, and is environmentally friendly. It also has the characteristics of low noise and no vibration, allowing users to enjoy a quiet life.
brand introduction:
Haier Group was founded in 1984. It is a company focusing on home appliances and smart homes and has a large global user base. As one of the representatives of Chinese home appliance companies and one of the leaders in the global home appliance market, Haier adheres to the strategic goal of "focusing on value creation, treating the world as a market, and driving corporate development with innovation" and develops in the direction of an enterprise that strives for excellence and continuous innovation. . Haier not only challenges the technical field, but also actively advocates green environmental protection, closeness to consumers and other social responsibilities, and has very high quality and credibility.
FAQ:
1. How about the maintenance service of Haier whole house heat pump?
Our air source heat pump provides a 5-year warranty and cooperates with a number of local repairers to provide users with immediate maintenance services.
service.
2. Does heat pump heating require the purchase of special floors or floor heating?
No, our Haier whole-house heat pump can be connected to various types of floor heating and floor furniture for use.
3. Which houses are Haier whole-house heat pumps suitable for?
Haier whole-house heat pumps are suitable for a variety of building types and apartment types, whether they are renovations, renovations or partially new properties.
