NEW SOLUTIONS FOR ECO & EFFICIENT HOT WATER

Haier EIP+ Series Air Source Heat Pump Water Heater

BRING ECOLOGY & EFFICIENCY TO A NEW LEVEL

20240704103916

Heat pumps utilize free and renewable energy from the outside air, resulting in cost savings for users while also reducing the environmental impact of carbon emissions. Compared to conventional electric storage water heaters, heat pumps can save up to 80% of energy for domestic hot water in households. This makes them suitable for both new build and renovated homes.

GREEN FOR YOU AND THE EARTH

The new natural refrigerant, R290, is an

environmentally friendly choice that

reduces carbon emissions and contributes

to the global goal of carbon neutrality.

ECO - R290 NATURAL REFRIGERANT

New R290 Refrigerant, More Eco-friendly

In order to achieve carbon neutrality and mitigate global warming, the Haier EIP+ series air source heat pump water heater uses R290 natural refrigerant, which is a trend of advanced household water solutions, to offer sustainable, green, and comfortable hot water solutions.

Natural, Non-toxic, and Free of Ozone Depletion

The R290 is a high-purity propane refrigerant with a global warming

potential (GWP) of 3. This indicates that it will contribute less to ozone

depletion compared to other alternatives.

ECO - R290 NATURAL REFRIGERANT

Excellent Thermodynamic Performance

The R290 refrigerant oﬀers excellent thermodynamic performance,

allowing for higher water temperatures to meet various application

demands.

Up to 65°C Water Temperature

The heat pump works alone to make the water temperature as high as 65 °C, and the water mixing rate at 40 °C can reach 125%, which is equivalent to 25% capacity increase, saving power and enjoying surging water.

Higher Water Temperatures

for Shower and Bacterial Proof

20240704160347

HIGH-EFFICIENCY

AND ENERGY SAVING

The technologically advanced Haier EIP+ series air source heat pump water heater features full inverter technology and micro-channel condenser, resulting in lower energy consumption and higher heating eﬃciency.

EFFICIENCY 80% ENERGY SAVING

High Efficiency,

A+ ErP Energy Rating

Haier EIP+ series air source heat pump water heater achieves A+ energy rating, as illustrated in the product label.

COP3.6*, 80% Energy Saving

High eﬃciency means low energy costs, the Haier EIP+ series air source heat pump water heater can greatly reduce energy bills for users.

*Tested at 14°C operating conditions

EFFICIENCY 80% ENERGY SAVING

20240705105219

Improve performance

20240705105440

Increase heat transfer eﬃciency

20240705105524

Reduce power consumption

1mmsuper thin flow

path, lower resistance,

faster flow speed and

higher thermal efficiency

Micro-channel Condenser

Upgraded for R290 Refrigerant

The surface contact heat exchange area is larger,

and the refrigerant is fully fed and heat is exchanged

in a very small flow path, which greatly improves the

efficiency of heat exchange compared to traditional

heat exchangers.

Multi-path design with multiple ultra-fine micro-channels in each path, enabling more efficient heat transfer while reducing flow resistance and lowering power consumption, resulting in a performance improvement.

The larger heat transfer

surface area leads to a

increase in heat transfer

efficiency

Uniform heating with

temperature differences of

within 4°C between the upper and lower layers, minimal stratification of hot

water, outperforming copper

pipe heat exchangers, and

effectively reducing power

consumption.

EFFICIENCY 80% ENERGY SAVING

Full Inverter Technology,

Energy-Saving with Continuously Variable

The high-quality inverter compressor and DC fan, combined

with integrated inverter drive module, signiﬁcantly improve

electrical energy utilization. The system dynamically adjusts

input power based on unit operation, ensuring optimal

energy eﬃciency at all times. It maintains stability

even in low-temperature conditions and achieves

even greater energy saving during

high-temperature conditions.

Inverter Compressor

Adjusting input power

based on the machine's

operational status to

achieve high energy

efficiency.

DC Fan

Under the same air

volume, the power of

the DC fan is 40% to

50% lower than AC fan,

making the system

more energy-efficient.

imagecompress8

EFFICIENCY 80%ENERGY SAVING

Dual Power Heating, Enables Faster Hot Water Production

There are locations in the United states of america as well as ationally. The organization was established in 2000 on the basis of a small idea conceived by its promoters that was incepted.

Hot Water is Available

in Less Tim

In the cold winter, the compressor increases input power to stabilize heat production.

2024-07-05 151006

When a large amount of hot water is urgently needed, dual power is more eﬃcient.

EFFICIENCY 80%ENERGY SAVING

Smart Defrost, More

Efficient and Energy Saving

Haier smart defrosting control system is equipped with a four-way

valve and an electronic expansion valve with higher refrigerant ﬂow

control accuracy, the defrosting eﬀect is more suﬃcient, so that it is

not easy to frost in low temperature conditions.

	When tested at 7/6°C, the	When tested at 7/6°C, the
	evaporator's frosting condition.	evaporator's frosting condition.

imagecompress12 2

EXCELLENT PERFORMANCE

YEAR AFTER YEAR

Better heating, better reliability. The R290 dedicated

compressor and high-quality enamel tank oﬀer a longer

service life and stable heating performance.

HIGH QUALITY AND DURABLE

R290 Dedicated Compressor, High-quality and Efficient

Optimized internal structure of the compressor eﬀectively reduces refrigerant storage inside the compressor, enhancing the refrigerant circulation in the system.

High Efficiency/Economy

●By using an efficient new pump structure, efficiency increases by more than 2%.

●Based on the characteristics of R290, dedicated refrigeration compressor oil enhances system efficiency, even in situations with low charge levels.

Low Noise Operation

Optimize motor airflow channel and compressor noise reduction structure, result in a 2.5~3dB(A) decrease in compressor noise level.

HIGH QUALITY AND DURABLE

High-quality Enamel Tank, Longer Service Time

High-quality enamel tank, featuring an exclusive design for water heaters,

oﬀers a longer service life and stable heating performance.

Professional Quality

Haier has upgraded its enamel technology to enhance uniformity and create a high-density enamel tank that is resistant to corrosion, acid, alkali, and extremely durable.

Advanced Formula

By using high-quality enamel powder (made in the USA) and upgrading the formula to eliminate the pinhole, the granule weight will be lighter and the anti-corrosion performance will be better.

Production Technology

The enamel material is melted at super high temperature, the enamel layer will isolate the water and steel plate to prevent rust and scale. The tank will have longer service life.

POWER YOUR HOME THE SMART WAY SAVE ENERGY BILLS

With its advanced capabilities, the multi-energy connected feature allows users to choose economical electrical energy, helping them save energy and reduce costs.

ECONOMICAL MULTI-ENERGYCONNECTED

Power signal	If you need to meet water usage priority	If you need to balance between water usage and economic benefit	If you need maximum economic benefit
PV	Electric signal E1-Heat pump and electric heating meanwhile when there is sufficient PV F1-Activate and heat immediately, no signal returns to the current mode MODE AUTO	Electric signal E1-Heat pump and electric heating meanwhile when there is sufficient PV F3-Activate and heat immediately, mode is disabled. Keep the water temperature at 40°C without signal	Electric signal E1-Heat pump and electric heating meanwhile when there is sufficient PV F4-Activate and heat immediately, No heating when there is no signal . (Former set mode is disabled.)
Off- peak	If there are intermittent signals from the power company Electric signal E1-Heat pump and electric heating meanwhile F2-Only activate and heat in the heating time of the current mode MODE AUTO	If there are intermittent signals from the power company Electric signal E2-Heat pump (electric heating is only started after the water temperature is 65°C) F3-Activate and heat immediately, mode is disabled. Keep the water temperature at 40°C without signal	If there are intermittent signals from the power company Electric signal E2-Heat pump (electric heating is only started after the water temperature is 65°C) F4-Activate and heat immediately, No heating when there is no signal . (Former set mode is disabled.)
Off- peak	If it is during a fixed time period with off-peak electricity MODE ECO	If it is during a fixed time period with off-peak electricity MODE ECO	If it is during a fixed time period with off-peak electricity MODE ECO

ECONOMICALMULTI-ENERGYCONNECTED

Combine with boiler, solar thermal, PV, save energy and reduce costs.

Solar Water Heater & Heat Pump Water Heater

Priority given to solar energy, greatly reduce energy bills for users.

Gas Boiler & Heat Pump Water Heater

As a compensatory energy source for heat pumps to achieve higher water temperatures.

PV & Heat Pump Water Heater

Select PV power to save electricity cost.

imagecompress20

A QUIET HOME, A COMFORTABLE LIFE

Haier advanced features, including a full inverter system, a soundproof enclosure design, and a dedicated mute mode, guarantee whisper-quiet operation without compromising performance.

COMFORTABLE LOW NOISE

Operating at 40dB,

as Quietas a Library

imagecompress21

2024-07-10 101629

Full Inverter System

Inverter compressor and

DC fan ensure smooth

and low noise operation.

Soundproof Enclosure

Design

Eﬀectively isolates the

operating noise of the

compressor.

product-292-116

Mute Mode

Set the time for mute

operation, operate quietly

during the night.

A NEW DEFINITION OF COMFORT CONTROL

Home gets smarter, life gets simpler. Equipped with a TFT screen and smart connectivity, the Haier EIP+ series air source heat pump water heater oﬀers superior comfort in an eﬃcient and intuitive manner. Experience the joy of a smart life.

imagecompress22 1

SMART & CONVENIENT

Connect and Control from Anywhere, Anytime

Haier EIP+ series air source heat pump water heater can be operated from your mobile devices via WiFi. With the hOn app, you can easily control the heat pump anytime from anywhere.

imagecompressimagecompress23

hOn App: Your Smart Life Companion

Your appliance can be connected to your home wireless network and operated remotely using the app.

Getting started

Ensure that your home WiFi network is turned on.

After startup, it will enter fast pairing mode without the need for manual operation.

If the connection is successful, the WiFi icon will always be on.

On your mobile device

Download the app from https://hon-smarthome.com/.

Add your appliance and set up the WiFi connection.

SMART & CONVENIENT

Large Screen Display

Meet Various Water Usage Needs

111

AUTO Mode

Automatically heat water to set temperature and maintain it.

112

113

ECO Mode

In this mode, priority of heat pump heating; User entered timer settings.

114

ELEC Mode

In this mode, the backup element is used as the only heat source. This function ensures hot water supply when the heat pump is not working properly.

115

BOOST Mode

Heat pump and backup element are activated at the same time.

116

VAC Mode

Maintains a minimum temperature to prevent freezing.

SMART & CONVENIENT

Intuitive Operational Information

Information

Query the electric energy consumption information of the unit.

119

Customizable Control Experience

120 Mute Mode

In this mode, the heat pump operates quietly.

121 Bactericidal Mode

Users can set the sterilization temperature, the frequency of sterilization, and the start time of sterilization.

Personalized sterilization settings

Set the sterilization temperature, which is adjustable from 55°C to 75°C.

Set the frequency of sterilization, which can be selected as single, weekly, or monthly.

Set the start time of sterilization, adjustable from 0 to 24 hours.

imagecompress123

EASY INSTALLATION

FOR YOUR PEACE OF MIND

The installation of the HaierEIP+ series air source heat pump water heater is quick and easy, thanks to its innovative design.

ALL IN ONE INTEGRATED

Elegant Design

The pure white body is aesthetic and fashion,

while the shield-shaped display symbolizes

security and reliability.

imagecompress26

Easy Installation

There is no need for additional refrigerant connection pipes

or unnecessary pipelines, ensuring convenient installation.

INSTALLATION INSTRUCTIONS

2024-07-09 101549

2024-07-09 101631

COMPONENTS

1 Evaporator	7 Four-way valve
2 Elctronic expansion valve	8 DC fan
3 Compressor	9 Display panel
4 Enamel tank	10 Drain pan
5 Micro-channel condenser	11 Electric heating element
6 Air channel	12 Coil condenser

TECHNICAL PARAMETERS

2024-07-09 103057

Model	HP200M7-F9	HP200M7C-F9	HP250M7-F9	HP250M7C-F9
Tank
Total cylinder capacity(L)	194	185	250	240
Rated voltage/frequency(V/Hz)	220-240/50	220-240/50	220-240/50	220-240/50
Tank Max pressure(kPa)	700	700	700	700
Corrosion protection	Magnesium rod	Magnesium rod	Magnesium rod	Magnesium rod
Insulation protection rating	IPX4	IPX4	IPX4	IPX4
Performances(7°C/6°C ambient air temperature, 10°C/55°C water temperature)
COP@7°C(EN16147)	3.2	3.2	3.23	3.21
COP@14°C	3.6	3.6	3.6	3.6
Power input by electric backup(W)	1500	1500	1500	1500
Rated power input by heat pump(W)	320	320	320	320
Maximum power input by heat pump(W)	535	535	535	535
Maximum power input(W)	2035	2035	2035	2035
Heating water capacity(L/h)	24	24	24	24
Heating up time(10°C/55°C)@7°C(h)	7	6.8	10.5	10.3
Default temperature setting(°C)	65	65	65	65
Temperature setting range-with heater(°C)	35-75	35-75	35-75	35-75
Maximum temperature output for the heat pump only(°C)	65	65	65	65
Max working pressure of refrigerant(MPa)	1.0/3.3	1.0/3.3	1.0/3.3	1.0/3.3
Refrigerant type/weight(kg)	R290/0.15	R290/0.15	R290/0.15	R290/0.15
Sound power level *@1 metre(dB(A))	50	50	50	50
V40(L)	239	228	307	295
Ambient temperature of heat pump(°C)	-7-45	-7-45	-7-45	-7-45
Dimension and connections
Water inlet and outlet connection	Rp 3/4	Rp 3/4	Rp 3/4	Rp 3/4
TPR valve connection	Rp 3/4	Rp 3/4	Rp 3/4	Rp 3/4
Drain & water inlet connection	Rp 3/4	Rp 3/4	Rp 3/4	Rp 3/4
Product dimensions(mm)	6006201694	6006201694	6006201989	6006201989
Packing dimension with pallet(mm)	7366951940	7366951940	7366952250	7366952250
Net/gross weight(kg)	86/109	96/119	98/121	107/131
Filled weight of the appliance(kg)	281	282	347	349

●THE COP was measured under test conditions with an ambient air temperature of 20°C/15°C (Dry Bulb/Wet Bulb) and heating of the waterfrom 15°C to 55°C during water heater operation.

●The noise level was measured at 1 m from the water heater during a Noise Test conducted to Standard GB/T 23137 in a hemi-anechoicchamber with in a laboratory

Hot Tags: haier m7 air energy water heater, China haier m7 air energy water heater manufacturers, suppliers, factory, Ultra High Efficiency Heat Pump, Home Heating Machine, New Heating Heat Pump System, Winter Heating Heat Pump, Air Energy Heat Pump Hot Water, Comfort Heat Pump

Haier M7 Air Energy Water Heater

Choose Economical Electrical Energy

Multi-energy Connected

Personalized sterilization settings
